Energy efficient doors by aluplast

Advanced performance and maximum design flexibility

Our door range has been developed to redefine the design potential of PVC-U doors, maximising opportunities for manufacturers and installers.

A high-end architectural aesthetic in low maintenance and energy efficient PVC-U systems.

Our energy efficient French doors, entrance doors, patio and lift-and-slide doors are engineered to push the boundaries of design, going head-to-head with aluminium sliding door systems, while offering up to Paasiv Haus equivalent standards of performance.

Available in our next generation foils aludec, our aluminium foiled finish option and woodec, our ultra-life like warm to the touch, timber alternative, they open up new architecturally driven markets to PVC-U manufacturers and their customers.

Smart-Slide

Smart-Slide challenges convention. It’s been engineered to expand the reach of PVC-U patio doors into an architectural space. It combines exceptional design flexibility with effortless operation, in an efficient to manufacture patio door.

Edit

Capable of spanning openings of 5m X 2.4m with just two sashes, the aluplast Smart-Slide door delivers impressive design flexibility. This includes uninterrupted sightlines as standard, effortless operation and next generation security with locking on all four sides of the sash.

Edit
  • Spans up to 5m at up to 2.4m tall, in only two panels!
  • Individual sash weights of up to 200kg
  • Soft-close/self-closing
  • Next generation locking mechanism, locking on all four sides of the sash; plus part open secure locking
  • PAS24 as standard
  • 24-40mm glazing options
  • U-values of 3Wm2k and Door Energy Rating (DER) of A+
  • Excellent weather sealing including deflection test to 970Pa and 1515 Pa with reinforcement; Air infiltration test 150 Pa; and water 455 Pa and 600Pa with reinforcement
  • ecotech technology
  • Choice of 40 foil finishes including aludec and woodec options

Lift-and-Slide

The aluplast Lift-and-Slide Door employs an innovative easy-lift mechanism that elevates sashes when opened and lowers them on to the track when closed. It means a fully closed-door rests over lower weather seals improving weather tightness, thermal and acoustic insulation.

Suitable for manufacture as an entry-level system to a premium offering, it delivers manufacturing efficiency savings of up to 40% over competitor systems.

Edit

Majoring on a Passive Haus equivalent standard performance the aluplast Lift-and-Slide door is a modular system, achieving U-values as low as 0.65 W/m2K.

It’s capable of spanning openings of 6.5m X 2.8m with just two sashes, leaving sightlines uninterrupted and delivering complete design flexibility.

Edit
  • Slim sightline 85mm system
  • Modular – available in entry, standard and premium options
  • Light touch easy-operate lift-and-slide opening and closing mechanism
  • Thermally broken aluminium optional threshold
  • Accommodates glazing units of up to 52mm
  • Ultra-low sightline option on the fixed sash of just 32mm
  • U-values as low as 65 W/m2K – a Passive Haus standard equivalent
  • Maximum width/height up to 6.5m X 2.8m
  • Maximum sash weight of up to 300kg
  • Flush cill option
  • Ecotech technology
  • Choice of 40 foil finishes including aludec and woodec options

Entrance doors

Energy efficient and with a choice of fully sculptured, contemporary SquareLine or Flush Sash options, our door range has been developed to maximise design reach, while minimising stock holding. Combined with our range of standard foils, plus aludec and woodec it gives your customers the flexibility that they need to win business.

Edit

We offer three entrance door systems, Ideal 70 which features a fully sculptured detail; Ideal 4000, our contemporary SquareLine door system; and flush sash options on both. Each is available in our next generation foil range, aludec, which accurately replicates aluminium finish options and woodec, which offers an ultra-life like match to timber.

Edit
  • Choose from Ideal 70, Ideal 4000 or open out Flush Sash Door options
  • Advanced thermal performance including u-values as low as 1.2 W/m2K
  • Ecotech technology
  • Choice of 40 foil finishes including aludec and woodec options

French doors

Our Flush French Door option across the Ideal 70 and Ideal 4000 systems gives fabricators the flexibility to manufacture either a contemporary or period option, without increasing stock holding. Alternatively opt for a sculptured finish with the Ideal 70 or contemporary SquareLine finish with the Ideal 4000

Edit

Developed to offer fabricators maximum flexibility and advanced performance we offer three French Door Systems: the sculptured Ideal 70, urban Ideal 4000, plus a Flush Sash entrance door option on both systems.

Edit
  • Choose from Ideal 70, Ideal 4000 or open out Flush Sash Door options
  • Advanced thermal performance including u-values as low as 1.2 W/m2K
  • ecotech technology
  • Choice of 40 foil finishes including aludec and woodec options

Could you tell the difference?

aludec. The appearance of aluminium but without the hassle

aluplast ecotech
